DCA-85USJ
Part Number: 207264
The Ultra-Silent DCA-85USJ generates standby output of 88 kVA/70 kW and prime output of 82kVA/66kW. Powered by a 102-horsepower, 4-cylinder John Deere 4045TF275 diesel engine, the DCA-85USJ also features improved fuel efficiency and voltage regulation, and residual value that is unmatched by any other generator. The generator’s integrated fuel tank has a 24-hour run time and the unit is offered with a standard electric starting system and improved frequency regulation of 0.25 percent.
| Performance Data |
| |
|
| Standby Output |
70 kW , 88 kVA |
| Prime Output |
66 kW , 82 kVA |
| Generator RPM |
1800 |
| Generator Design |
Revolving Field Self-Ventilated Dip-Proof Single Bearing |
| Voltage Regulation - (No Load to Full Load) |
1 % |
| Power Factor |
0.8 |
| Armature Connection |
Star with Neutral / Zigzag |
| Excitation |
Brushless with AVR |
| No. Poles |
4 Pole |
| Frequency |
60 Hz |
| Available Voltages - 3 Phase |
208, 220, 240, 416, 440, 460, 480V Switchable Volts |
| Available Voltages - Single Phase |
120, 127, 139, 240, 254, 277 Switchable Volts |
| Amps - Single Phase 120V |
182.2 (4 Wire) 250x2 (Zigzg) Amps |
| Amps - Single Phase 240V |
91.2 (4 Wire) 250 (Zigzg) Amps |
| Amps - Three Phase 240V |
197 Amps |
| Amps - Three Phase 480V |
99 Amps |
| Insulation |
Class F |
| Sound Level dB(A) - Full Load at 23 feet |
61 dB(A) |
| |
| Power Source |
| |
|
| Engine Make / Model |
John Deere 4045TF275 |
| |
| Dimensions |
| |
|
| Overall Length |
109 in. , 277 cm |
| Overall Width |
49 in. , 124 cm |
| Overall Height |
71 in. , 180 cm |
| Approx. Net Wt. Dry |
4780 lbs. , 2168 kg. |
|
