| Performance Data |
| |
| Prime Output kW (kVA): 120 (150) |
| Design: Revolving Field, Self-Ventilated, Drip-Proof, Single Bearing |
| No. Poles: 4 |
| Excitation: Brushless with AVR |
| Generator RPM: 1800 |
| Voltage - 3 phase: 208, 220, 240, 416, 440, 480 |
| Voltage - Single phase: 120, 127, 139, 240, 254, 277 |
| Armature Connection: 12-Lead WYE |
| Amps - Single Phase 120V: 700A |
| Amps - Single Phase 240V: 1000A |
| Amps - Three Phase 208V: 413A |
| Voltage Regulation - (No Load to Full Load): ±1% |
| Power Factor: 0.8 |
| Frequency: 60 |
| Insulation: Class H |
|
| |
| Power Source |
| |
| Engine Make/Model: Volve, TAD720GE |
| Starting System: Electric Motor, Solenoid Shift |
| Design: Direct Injection, Turbocharged, Aftercooled |
| Displacement cc: NA |
| No. of Cylinders: 4 |
| Bore/Stroke in. (mm): 4.25 x 5.12 (108 x 130) |
| HP at Rated Speed: 203 |
| Fuel Consumption - |
| Full Load gph (lph): 4.2 (16) |
| 3/4 Load gph (lph): 3.3 (12) |
| 1/2 Load gph (lph): 2.4 (9) |
| 1/4 Load gph (lph): 1.4 (1.8) |
| Coolant Capacity gal. (liters): 3.7 (14.0) |
| Oil Capacity gal. (liters): 5.3 (20) |
| Battery: 12VDC System |
|
| |
| Dimensions |
| |
| Overal Length: 100 in. (254 cm.) |
| Overal Width: 48 in. (122 cm.) |
| Overall Height: 87 in. (221 cm.) |
| Aprox. Net Wt. lbs. (kg): 6480 (2939) |
|
| |
| Optional Trailers |
| |
| Trailer Dimensions - in. (cm): 180 x 90 x 22 in. (457 x 229 x 56 cm.) |
| No. of Axles: Tandem Axle, Pintle-Eye or Ball, Electric or Hydraulic Brakes |
| Fuel Tank Capacity - gal. (liters): 160 (606) |
